1972-1977 Lamborghini Urraco USA Rivestimenti Esterni (28)

Maintenance Parts:

Brakes

PN	Item	Diagram
003220800	Brake Pad Rear - Urraco - Jalpa - Sold Each Rear Brake Pad Kits		Avail to order Our Price: $99.00

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.44

Drivetrain

PN	Item	Diagram
001505914	Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa Oil Cartridge. Note: these are ordered directly from the factory. Brand/Model/Color may differ from the picture. We have no control as to what is sent when they are ordered.		Current Stock: 1 Our Price: $86.51
002108644	Thrust Bearing Thrust Bearing		Current Stock: 1 Our Price: $1,856.19
002106838	Clutch Cylinder Rod Clutch Cylinder Rod		Avail to order Our Price: $68.44
002108645	Engine Flywheel & Crown Engine Flywheel & Crown		Avail to order Our Price: $7,713.94
002108646	NLA (No longer Available to order) Clutch Plate		Avail to order Our Price: $680.73

Fuses-Bulbs-Relays

PN	Item	Diagram
001605819	Relay Relay		Current Stock: 1 Our Price: $44.66

Gaskets

PN	Item	Diagram
001526484	Engine Gasket Set Urraco 2000 Engine Gasket Kit Urraco 2000		Avail to order Our Price: $1,761.28
001526486	Engine Gasket Set Uracco 3000 Engine Gasket Kit Uracco 3000		Avail to order Our Price: $2,980.05
001526465	Grommet and Oil Seals Set - Urraco 2400 Grommet and Oil Seals Set Urraco 2400		Avail to order Our Price: $338.88
001526464	Grommet and Oil Seals Set - Urraco 2000 Grommet and Oil Seals Set Urraco 2000		Avail to order Our Price: $295.20
001526466	Grommet and Oil Seals Set - Urraco 3000 Grommet and Oil Seals Set Urraco 3000		Avail to order Our Price: $306.19

Ignition

PN	Item	Diagram
001609428	Distributor/Spark Plug Wiring Distributor/Spark Plug Wiring		Avail to order Our Price: $1,398.62
001609592	Distributor Cap Cap		Avail to order Our Price: $390.62
001612293	Urraco Wiring Harness - USA Urraco Wiring Harness		Avail to order Our Price: $1,856.19
001611700	Urraco Wiring Harness Urraco Wiring Harness		Avail to order Our Price: $1,833.82

Sensors

PN	Item	Diagram
002408637	REVERSE SWITCH REVERSE SWITCH		Avail to order Our Price: $136.72
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY		Avail to order Our Price: $150.12
001719309	THERMOSTAT Coolant Thermostat		Avail to order Our Price: $350.78

Open All

Select Group and TAV

< Previous Next >

TAV: 28 - Rivestimenti Esterni

1972-1977 Lamborghini Urraco USA Rivestimenti Esterni (28)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Urraco Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
0	006910040	Rf Fender Cover.	1 req	Avail to order Our Price: $2,355.64
0	006910050	Right Skirt Cover.	1 req	Avail to order Our Price: $954.21
0	006921145	Right Door Unit	1 req	Avail to order Our Price: $20,977.06
0	006990094	Rh Long Rear Fin	1 req	Avail to order Our Price: $699.24
0	006990092	Rh Medium Rear Fin	1 req	Avail to order Our Price: $699.24
0	006990090	Rh Short Rear Fin	1 req	Avail to order Our Price: $699.24
0	006910070	Rr Fender Cover.	1 req	Avail to order Our Price: $6,716.54
1	006990030	Rh Headlamp Bezel	1 req	Avail to order Our Price: $150.87
2	006910130	Rh Headlight Hous.	1 req	Avail to order Our Price: $2,646.37
3	006910020	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
4	006910030	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
5	006910100	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
6	006910190	This item is no longer available	1 req
7	006910126	Complete Engine Cover	1 req	Avail to order Our Price: $6,224.54
8	006910120	Rear Spoiler - 1-	1 req	Avail to order Our Price: $699.24
9	006910121	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
10	006910122	Rear Spoiler - 3-	1 req	Avail to order Our Price: $699.24
11	006910123	Rear Spoiler - 4-	1 req	Avail to order Our Price: $699.24
12	006910124	Rear Spoiler - 5-	1 req	Avail to order Our Price: $699.24
13	006910125	Rear Spoiler - 6-	1 req	Avail to order Our Price: $699.24
14	006102515	Bonnet Badge	1 req	Current Stock: 5 Our Price: $1,018.12
15	009610010	This item is no longer available	1 req
16	006990031	Lh Headlamp Bezel	1 req	Avail to order Our Price: $365.64
17	006910031	Lower Front Centr.Shelf	1 req	Avail to order Our Price: $1,694.39
18	006910041	Lf Fender Cover.	1 req	Avail to order Our Price: $2,355.64
19	006910051	Left Skirt Cover.	1 req	Avail to order Our Price: $954.21
20	006921146	Lh Door Assembly	1 req	Avail to order Our Price: $20,977.06
21	006990095	Lh Long Rear Fin	1 req	Avail to order Our Price: $699.24
22	006990093	Lh Medium Rear Fin	1 req	Avail to order Our Price: $699.24
23	006990091	Lh Short Rear Fin	1 req	Avail to order Our Price: $699.24
24	009610071	This item is no longer available	1 req
25	009510190	This item is no longer available	1 req
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
