1966-1972 Lamborghini Miura USA Steering Column (26)

Maintenance Parts:

Brakes

PN	Item	Diagram
003106765	FRONT BRAKE PADS JARAMA AND MIURA FRONT BRAKE PADS JARAMA AND MIURA		Avail to order Our Price: $456.30
003206764	Brake Pad Rear - Espada - Miura - Jarama - Sold Each Rear Brake Pad		Avail to order Our Price: $78.63

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.44

Drivetrain

PN	Item
290400000	Miura Pre-assembled Clutch Cyl Miura Pre-assembled Clutch Cyl	Avail to order Our Price: $1,887.62
002103598	Clutch Rod Clutch Rod	Avail to order Our Price: $700.05
002105449	Clutch Plate Clutch Plate Complete	Avail to order Our Price: $1,887.62
008502505	SEE PN 086311430A Bearing	Avail to order Our Price: $60.72
002126614	Engine Flywheel Muira Engine Flywheel DISCONTINUED - NLA - CONTACT US	Current Stock: 1 Our Price: $697.64

Fuel-Air

PN	Item	Diagram
001320172	Air Filter - Carbureted Air Filter Early Countach, Miura, Jarama, Espada SEE PN 001320172KN for Performance filter option		Avail to order Our Price: $502.37
001320172KN	Performance filter for Countach/Espada/Jarama/Miura High Flow performance filter.		Current Stock: 1 Our Price: $130.02

Gaskets

PN	Item
001526493	Engine Gasket Set - Jalpa - Miura Engine Gasket Kit Jalpa and Miura See also 001526473 grommet & oil seals set	Avail to order Our Price: $1,098.80
001526473	Grommet and Oil Seals Set - Jalpa - Miura Grommet and Oil Seals Set Jalpa - Miura	Avail to order Our Price: $348.55
001526483	Miura Engine Gasket Kit Engine Gasket Kit See pn 001526463 for seals	Avail to order Our Price: $1,850.46

Sensors

PN	Item	Diagram
002409171	DISCONTINUED - NLA Reverse Light Switch		Avail to order Our Price: $236.33
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY		Avail to order Our Price: $150.12

Open All

Select Group and TAV

< Previous Next >

TAV: 26 - Steering Column

1966-1972 Lamborghini Miura USA Steering Column (26)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Miura Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008401807	Washer 18.5x30x2.5	1 req	Avail to order Our Price: $23.93
2	004301790	NLA (No Longer Available)	1 req	*See Description
3	004303548	This item is no longer available	1 req
4	004305006	This item is no longer available	1 req
5	008251801	M18x1.5x28 Self-Locking Ring N	1 req	Avail to order Our Price: $42.05
6	004305009	STEERING WHEEL	1 req	Avail to order Our Price: $4,994.00
7	004305007	STEERING WHEEL HUB	1 req	Avail to order Our Price: $868.01
8	004301383	NLA (No Longer Available)	1 req	*See Description
9	004313277	LIGHT / HORN SWITCH	1 req	Avail to order Our Price: $1,798.44
10	008201006	M10Self Locking Nut	1 req	Avail to order Our Price: $8.80
11	004301183	Steering Bracket	1 req	Avail to order Our Price: $670.33
12	008522503	Needle Bearing	1 req	Avail to order Our Price: $23.78
13	008402504	Washer 25.5x33x2.5	1 req	Current Stock: 4 Our Price: $23.93
14	008575001	O-Ring I 47 Uni 3654	1 req	Current Stock: 10 Our Price: $2.00
15	008502503	Bearing	1 req	Avail to order Our Price: $158.78
16	004301390	Spacer	1 req	Avail to order Our Price: $88.26
17	008502503	Bearing	1 req	Avail to order Our Price: $158.78
18	004301424	Joint	1 req	Avail to order Our Price: $5,246.66
19	004302666	This item is no longer available	1 req
20	008611002	NLA	1 req	*See Description
21	008101021	Screw M10x1.5x125 Uni 5737	1 req	Avail to order Our Price: $21.40
22	008401006	Washer 22x10.5x2.5 Uni 1734/5s	1 req	Current Stock: 1 Our Price: $2.00
23	004301424	Joint	1 req	Avail to order Our Price: $5,246.66
24	004301408	This item is no longer available	1 req
25	008300406	This item is no longer available	1 req
26	WHT001197A	WASHER	1 req	Current Stock: 2 Our Price: $2.00
27	008100621	Screw M6x20 Uni 5739/5s/Z	1 req	Avail to order Our Price: $2.00
28	004301397	Indicator Return Lever Pin	1 req	Avail to order Our Price: $27.73
29	008860701	Tab 5x7.5 Unim 99	1 req	Avail to order Our Price: $8.80
30	004302566	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
