Maintenance Parts:

Belts

PN Item Diagram
001725107 Alternator/Coolant Pump Belt UP TO VIN 12582
Alternator/Coolant Pump Belt
view diagram Avail to order
Our Price: $142.24
Alternator/Coolant Pump Belt UP TO VIN 12582
004529536 Compressor Belt Until
Compressor Belt
view diagram Avail to order
Our Price: $211.71
Compressor Belt Until
001731857 Coolant Pump Alternator Belt after VIN 12583
Coolant Pump Alternator Belt
view diagram Current Stock: 1
Our Price: $122.08
Coolant Pump Alternator Belt after VIN 12583

Brakes

PN Item Diagram
003331672 Ebrake Pads Set (1 pair)
E Brake Pads Set (1 pair)
view diagram Avail to order
Our Price: $202.76
Ebrake Pads Set (1 pair)
003235293 Brake Pad Rear -Early Diablo - Sold Each
Rear Brake Pad 1991-1993 Diablo and 1994 Diablo SE
view diagram Avail to order
Our Price: $1,052.31
Brake Pad Rear -Early Diablo - Sold Each
003135292 Brake Pads Front - Jalpa - Early Diablo - Per Rotor
Front Brake Pads
view diagram Avail to order
Our Price: $524.67
Brake Pads Front - Jalpa - Early Diablo - Per Rotor

Common repairs and upgrades

PN Item Diagram
410860382 STEERING WHEEL COVER
STEERING WHEEL COVER WITH CREST LOGO
Current Stock: 2
Our Price: $22.58
STEERING WHEEL COVER
006329689 HIGH BEAM HEADLIGHT
HIGH BEAM HEADLIGHT
Avail to order
Our Price: $535.96
HIGH BEAM HEADLIGHT
0079004387 SHOCK ABSORBER
SHOCK ABSORBER FOR ANTERIOR COWLING
Current Stock: 2
Our Price: $139.79
SHOCK ABSORBER
0092004388 shock absorber for engine cowling
shock absorber for engine cowling
Current Stock: 4
Our Price: $253.09
shock absorber for engine cowling

Drivetrain

PN Item Diagram
001505914 Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa
Oil Cartridge. Note: these are ordered directly from the factory. Brand/Model/Color may differ from the picture. We have no control as to what is sent when they are ordered.
view diagram Current Stock: 15
Our Price: $86.65
Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa
002132599 CLUTCH PRESSURE PLATE - DIABLO
CLUTCH PLATE - NLA (No Longer AVAILABLE) FROM FACTORY. PLEASE CHECK WITH US FOR ALTERNATIVES - ABOUT 2 WEEK LEAD TIME
view diagram Avail to order
Our Price: $1,850.00
CLUTCH PRESSURE PLATE - DIABLO
002136948 Slave Clutch Cylinder Diablo / Countach
Slave Clutch Cylinder
view diagram Current Stock: 5
Our Price: $134.59
Slave Clutch Cylinder Diablo / Countach
004219984 Master Clutch Cylinder
Clutch Cylinder Control Assembly
view diagram Avail to order
Our Price: $350.78
Master Clutch Cylinder
07M115561B SPIN-ON FILTER CARTUCCIS FIL.OLIO
SPIN-ON FILTER CARTUCCIS FIL.OLIO
Avail to order
Our Price: $104.15
SPIN-ON FILTER    CARTUCCIS FIL.OLIO
002129353 THRUST SLEEVE
THRUST SLEEVE - NLA (No Longer AVAILABLE) FROM FACTORY. PLEASE CHECK WITH US FOR ALTERNATIVES
view diagram Avail to order
Our Price: $1,630.19
THRUST SLEEVE
002132598 Clutch Mechanism - Early Diablo
Clutch Mechanism
view diagram Avail to order
Our Price: $1,674.86
Clutch Mechanism - Early Diablo
0017002473 Water Pump (2WD w/o Power Stearing) (1991-1994)
Coolant Pump 2WD W/o
view diagram Avail to order
Our Price: $5,306.12
Water Pump (2WD w/o Power Stearing)  (1991-1994)
0017002474 Water Pump (2WD With Power Steering) (1991-1994)
Coolant Pump 2WD With
view diagram Current Stock: 1
Our Price: $6,101.30
Water Pump (2WD With Power Steering) (1991-1994)
0R1320001 NLA (No Longer Available)
SPEED SENSOR KIT
view diagram Avail to order
Our Price: $940.84
NLA (No Longer Available)
002132599K 1991 - 1994 Diablo Clutch Disk - KEVLAR HI-PERF
1991 - 1994 Diablo Clutch Disk - KEVLAR HI-PERF - Clutchtex - TZ-3022 T3
Avail to order
Our Price: $900.97
1991 - 1994 Diablo Clutch Disk - KEVLAR HI-PERF
001434601 Oversized Shoulder Washer
Oversized Shoulder Washer
Avail to order
Our Price: $77.14
Oversized Shoulder Washer
001434600 Oversize Thrust Washer
Oversize Thrust Washer
Avail to order
Our Price: $77.14
Oversize Thrust Washer
005129802 Front Shock Absorber
Front Shock Absorber
Current Stock: 4
Our Price: $1,159.75
Front Shock Absorber

Fuel-Air

PN Item Diagram
07M133843 Air Filter - LM002, Countach, Diablo, Murcielago
Please Check your Part Manual for a Description For performance filters see PN: 07M133843A
view diagram Avail to order
Our Price: $31.69
Air Filter - LM002, Countach, Diablo, Murcielago
002024398 Fuel Pump
Fuel Pump
view diagram Current Stock: 6
Our Price: $762.25
Fuel Pump
07M133843KN K&N Air Filter - LM002, Countach, Diablo, Murcielago
K&N's replacement air filters are designed to increase horsepower and acceleration while providing excellent filtration. These filters are washable and reusable and are custom designed to fit into your existing factory air box. Their drop-in design means adding performance is simple.
Avail to order
Our Price: $70.48
K&N Air Filter - LM002, Countach, Diablo, Murcielago
07M133843A Air Filter - SPORT PERFORMANCE FILTER
Performance filter replacement for 07M133843 Air Filter - Murcielago SV LP 670-4
Avail to order
Our Price: $782.61
Air Filter - SPORT PERFORMANCE FILTER
AMAIRD Hi-Performance aFe Air Filter - Diablo/Murcielago - SPORT
Air Filter Murcielago - Diablo After Market aFe Air Filter 30-10133
Current Stock: 1
Our Price: $145.65
Hi-Performance aFe Air Filter - Diablo/Murcielago - SPORT
400201511A Fuel Filter - Diablo - Gallardo - Murcielago
FUEL FILTER
view diagram Avail to order
Our Price: $293.29
Fuel Filter - Diablo - Gallardo - Murcielago
002024396 FUEL INJECTOR (Sold Ea)
Manifold Upper CoverInjector
view diagram Avail to order
Our Price: $405.53
FUEL INJECTOR (Sold Ea)
002027648R Pressure Regulator Valve OE SPEC
Pressure Regulator Valve
Avail to order
Our Price: $273.87
Pressure Regulator Valve OE SPEC

Fuses-Bulbs-Relays

PN Item Diagram
006617095 Bulb for license plate lamp
Bulb LAMP SV8,5-8 5W
view diagram Current Stock: 42
Our Price: $11.09
Bulb for license plate lamp
006617091 Bulb 21w tail light
21w Bulb
view diagram Current Stock: 4
Our Price: $13.56
Bulb 21w  tail light
006617094 LAMP BA 15S 21W
Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)
view diagram Current Stock: 76
Our Price: $9.90
LAMP BA 15S 21W
N0177522 bulb
Headlight LAMP 12V/3W
view diagram Current Stock: 10
Our Price: $2.17
bulb
006311155 Relay
Relay
view diagram Avail to order
Our Price: $67.32
Relay
006311154 Relay
Relay
view diagram Avail to order
Our Price: $56.14
Relay
006329698 Bulb
Bulb
view diagram Avail to order
Our Price: $9.02
006030676 Light Relay
Light Relay
view diagram Current Stock: 3
Our Price: $184.13
Light Relay
006329694 Bulb Headlight
Bulb headlight
view diagram Avail to order
Our Price: $63.82
Bulb Headlight
006329695 BULB FOR FOGLIGHT
BULB FOR FOGLIGHT
view diagram Current Stock: 1
Our Price: $19.36
BULB FOR FOGLIGHT
006329696 Bulb 5w Front Turn Signal
5w Bulb front turn signal
view diagram Current Stock: 6
Our Price: $3.35
Bulb 5w Front Turn Signal
410947413 RED DOOR LIGHT
RED DOOR LIGHT - NLA (No Longer Available) TO ORDER FROM FACTORY PLEASE CONTACT US FOR OTHER OPTIONS.
Avail to order
Our Price: $92.91
RED DOOR LIGHT

Gaskets

PN Item Diagram
0R1320002 Diablo REAR Differential Seal Kit
Dif Seal Kit
Current Stock: 1
Our Price: $48.53
Diablo REAR Differential Seal Kit
001532102 Grommet and Oil Seals Set - Diablo 1991-1996
Diablo Grommet and oil seals Set Diablo 1991-1996
Avail to order
Our Price: $220.72
Grommet and Oil Seals Set - Diablo 1991-1996

Ignition

PN Item Diagram
001627730 DIABLO IGNITION ROTOR
DIABLO IGNITION ROTOR - NLA for FACTORY we have exact OE Replacement
view diagram Current Stock: 2
Our Price: $289.00
DIABLO IGNITION ROTOR
006134023 NLA (No Longer Available)
Spark Plug Wires ONLY for systems using distributor cap. Depending on production year may require different set: SEE PN: 006134279 & 001134281
view diagram Avail to order
Our Price: $743.20
NLA (No Longer Available)
001627728 DISTRIBUTOR CAP !991-1993 DIABLO
Cap Distributor Cap 1991 - 1993 NO LONGER AVAILABLE TO ORDER FROM FACTORY THIS IS OE SPEC OPTION
view diagram Current Stock: 3
Our Price: $340.00
DISTRIBUTOR CAP !991-1993 DIABLO
DiabloWireSet Spark Plug Wires 1991-1995 Diablo - Aftermarket
Spark Plug Wires 1991 through 1995 ONLY for systems using a Distributor cap
Avail to order
Our Price: $820.50
Spark Plug Wires 1991-1995 Diablo - Aftermarket
001630289 Spark Plug - Diablo
Spark Plug
view diagram Current Stock: 36
Our Price: $32.83
Spark Plug - Diablo
001630792N Coil pack OE SPEC REPLACEMENT
Coil pack OE SPEC REPLACEMENT
Avail to order
Our Price: $1,957.58
Coil pack OE SPEC REPLACEMENT

Misc

PN Item Diagram
008200605R OE spec alternative for 008200605
M6 Ncm 70 Urama Simmon Nut
Avail to order
Our Price: $1.94
OE spec alternative for 008200605
400093050D CTEK US-CD BATTERY CHARGER
Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month
Avail to order
Our Price: $373.98
CTEK US-CD BATTERY CHARGER
0R0000149 CLEANER FLUID 250ml
CLEANER FLUID
Current Stock: 1
Our Price: $70.78
CLEANER FLUID 250ml
009420126 WINDSHIELD WIPER BLADE
WINDSHIELD WIPER BLADE
view diagram Avail to order
Our Price: $36.40
WINDSHIELD WIPER BLADE

Sensors

PN Item Diagram
004526663 Cabin Air Temperature Sensor
Temperature Sensor
view diagram Avail to order
Our Price: $1,965.17
Cabin Air Temperature Sensor
07M905381 Phase Sensor
Phase Sensor
view diagram Avail to order
Our Price: $697.09
Phase Sensor
002408637 REVERSE SWITCH
REVERSE SWITCH
view diagram Avail to order
Our Price: $136.52
REVERSE SWITCH
0017006576 THERMOSTAT FOR DIABLO
WATER THERMOSTAT - -NLA (No Longer Available) DIRECT FROM LAMBORGHINI CONTACT US TO VERIFY AVAILABILITY FROM OTHER SOURCES
view diagram Current Stock: 3
Our Price: $295.00
THERMOSTAT FOR DIABLO
001536755 OIL TEMPERATURE THERMOSTAT
OIL TEMPERATURE THERMOSTAT - also used on Diablo 91-93 2wd and 94
view diagram Current Stock: 1
Our Price: $544.18
OIL TEMPERATURE THERMOSTAT
07M919529 Engine Air Temperature Sensor
Engine Air Temperature Sensor
view diagram Avail to order
Our Price: $308.18
Engine Air Temperature Sensor
001724565 Fan Motor Thermal Contact
Fan Motor Thermal Contact
view diagram Avail to order
Our Price: $244.50
Fan Motor Thermal Contact
0R1470226 Lambda (O2 Oxygen) Sensor - DIABLO - EARLY MURCIELAGO
Lambda (O2 Oxygen) Sensor - DIABLO - EARLY MURCIELAGO
Current Stock: 4
Our Price: $393.04
Lambda (O2 Oxygen) Sensor - DIABLO - EARLY MURCIELAGO
07L919501A Water Temperature Sensor
Water Temperature Sensor
view diagram Current Stock: 3
Our Price: $375.18
Water Temperature Sensor
001327641 Potentiometer TPS Throttle Position Sensor Diablos
Potentiometer
view diagram Avail to order
Our Price: $199.79
Potentiometer TPS Throttle Position Sensor Diablos

Tools and Tookits

PN Item Diagram
004129973 DIABLO FRONT TOW HITCH ASSEMBLY
Front Tow Hitch Assembly
Avail to order
Our Price: $1,525.98
DIABLO FRONT TOW HITCH ASSEMBLY
Open All

Select Group and TAV

TAV: 11.01.00 - Cylindar Head, Right

1991-1993 Lamborghini Diablo 2WD USA Cylindar Head, Right (11.01.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item # PN Item Qty Req *
1 001220819 Exhaust Valve
12 req Avail to order
Our Price: $1,595.27
Exhaust Valve
2 07M109675 Valve Guide Rubber Pad
24 req Current Stock: 51
Our Price: $16.91
 Valve Guide Rubber Pad
3 001220843 Valve Seal Cotter OnPlate
48 req Avail to order
Our Price: $8.95
Valve Seal Cotter OnPlate
4 07M109309 Valve Bowl
24 req Avail to order
Our Price: $39.46
Valve Bowl
5 07M109320 Valve Adjustment Shim 3.25 mm
24 req Current Stock: 51
Our Price: $12.06
Valve Adjustment Shim 3.25 mm
5 07M109320A Valve Adjustment Shim 3.30 mm
24 req Current Stock: 67
Our Price: $12.06
Valve Adjustment Shim 3.30 mm
5 07M109320B Valve Adjustment Shim 3.35 mm
24 req Current Stock: 60
Our Price: $59.93
Valve Adjustment Shim 3.35 mm
5 07M109320C Valve Adjustment Shim 3.40 mm
24 req Current Stock: 55
Our Price: $56.73
Valve Adjustment Shim 3.40 mm
5 07M109320D Valve Adjustment Shim 3.45 mm
24 req Current Stock: 35
Our Price: $12.06
Valve Adjustment Shim 3.45 mm
5 07M109320E Valve Adjustment Shim 3.50 mm
24 req Current Stock: 58
Our Price: $59.93
Valve Adjustment Shim 3.50 mm
5 07M109320F Valve Adjustment Shim 3.55
24 req Current Stock: 3
Our Price: $12.06
Valve Adjustment Shim 3.55
5 07M109320G Valve Adjustment Shim 3.60 mm
24 req Current Stock: 1
Our Price: $59.93
Valve Adjustment Shim 3.60 mm
5 07M109320H Valve Adjustment Shim 3.65 mm
24 req Current Stock: 6
Our Price: $62.23
Valve Adjustment Shim 3.65 mm
5 07M109320J Valve Adjustment Shim 3.70
24 req Current Stock: 6
Our Price: $59.93
Valve Adjustment Shim 3.70
5 07M109320K Valve Adjustment Shim 3.75 mm
24 req Avail to order
Our Price: $59.93
Valve Adjustment Shim 3.75 mm
5 07M109320L Valve Adjustment Shim 3.80 mm
24 req Current Stock: 56
Our Price: $59.93
Valve Adjustment Shim 3.80 mm
5 07M109320M Valve Adjustment Shim 3.85
24 req Current Stock: 24
Our Price: $12.06
Valve Adjustment Shim 3.85
5 07M109320N Valve Adjustment Shim 3.90 mm
24 req Current Stock: 32
Our Price: $59.93
Valve Adjustment Shim 3.90 mm
5 07M109320P Valve Adjustment Shim 3.95 mm
24 req Current Stock: 29
Our Price: $59.93
Valve Adjustment Shim 3.95 mm
5 07M109320Q Valve Adjustment Shim 4.00 mm
24 req Current Stock: 43
Our Price: $88.14
Valve Adjustment Shim 4.00 mm
5 07M109320R Valve Adjustment Shim 4.05 mm
24 req Current Stock: 25
Our Price: $12.06
Valve Adjustment Shim 4.05 mm
5 07M109320S Valve Adjustment Shim 4.10 mm
24 req Current Stock: 43
Our Price: $59.93
Valve Adjustment Shim 4.10 mm
5 07M109320T Valve Adjustment Shim 4.15 mm
24 req Current Stock: 40
Our Price: $12.06
Valve Adjustment Shim 4.15 mm
5 07M109320AA Valve Adjustment Shim 4.20 mm
24 req Current Stock: 59
Our Price: $12.06
Valve Adjustment Shim 4.20 mm
5 07M109320AB Valve Adjustment Shim 4.25 mm
24 req Current Stock: 83
Our Price: $12.06
Valve Adjustment Shim 4.25 mm
5 07M109320AC Valve Adjustment Shim 4.30 mm
24 req Current Stock: 50
Our Price: $12.06
Valve Adjustment Shim 4.30 mm
5 07M109320AD Valve Adjustment Shim 4.35 mm
24 req Current Stock: 70
Our Price: $12.06
Valve Adjustment Shim 4.35 mm
5 07M109320AE Valve Adjustment Shim 4.40 mm
24 req Current Stock: 73
Our Price: $59.93
Valve Adjustment Shim 4.40 mm
5 07M109320AF Valve Adjustment Shim 4.45 mm
24 req Current Stock: 58
Our Price: $12.06
Valve Adjustment Shim 4.45 mm
5 07M109320AG Valve Adjustment Shim 4.50 mm
24 req Current Stock: 62
Our Price: $12.06
Valve Adjustment Shim 4.50 mm
5 07M109320AH Valve Adjustment Shim 4.55 mm
24 req Current Stock: 69
Our Price: $12.06
Valve Adjustment Shim 4.55 mm
5 07M109320AJ Valve Adjustment Shim 4.60
24 req Current Stock: 17
Our Price: $12.06
Valve Adjustment Shim 4.60
5 07M109320AK Valve Adjustment Shim 4.65
24 req Current Stock: 28
Our Price: $12.06
Valve Adjustment Shim 4.65
5 07M109320AL Valve Adjustment Shim 4,70 mm
24 req Current Stock: 33
Our Price: $12.06
Valve Adjustment Shim 4,70 mm
6 07M109623A Valve Spring
24 req Avail to order
Our Price: $20.55
Valve Spring
7 07M109641 Spring Upper Washer
24 req Avail to order
Our Price: $20.55
Spring Upper Washer
8 07M109642 Spring Lower Washer
24 req Avail to order
Our Price: $19.06
Spring Lower Washer
9 07M109633A Inner Valve Spring
24 req Avail to order
Our Price: $6.70
Inner Valve Spring
10 001229714 Intake Valve
12 req Current Stock: 2
Our Price: $441.31
Intake Valve
11 001229368 Rh Intake Camshaft
1 req Avail to order
Our Price: $4,584.55
12 001229367 Rh Exhaust Camshaft
1 req Avail to order
Our Price: $4,584.55
13 WHT003019 Bushing 6.25x8x10 mm
4 req Current Stock: 2
Our Price: $12.73
Bushing 6.25x8x10 mm
14 008840802 Heli-Coil M8x1.25 L12
12 req Avail to order
Our Price: $3.73
15 463400100 5700 cc Fitted Head DX
1 req Avail to order
Our Price: $26,485.96
16 001229718 Exhaust Valve Guide
12 req Current Stock: 1
Our Price: $168.24
Exhaust Valve Guide
17 001229717 Intake Valve Guide
12 req Current Stock: 1
Our Price: $168.24
Intake Valve Guide
18 001220823 Exhaust Valve Seat
12 req Current Stock: 2
Our Price: $19.59
Exhaust Valve Seat
19 001229713 Intake Valve Seat
12 req Current Stock: 24
Our Price: $92.14
Intake Valve Seat
20 008931412 Plug
2 req Avail to order
Our Price: $110.04

* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
