1985 Countach 5000 Quatro - USA

Maintenance Parts:

Belts

PN	Item	Diagram
001613915	Alternator Drive Belt Alternator Drive Belt - NLA from Lamborghini warehouse - Secondary Source		Avail to order Our Price: $661.41

Brakes

PN	Item	Diagram
003113912	Brake Pad Brake Pad Set NLA from Lamborghini warehouse - Secondary Source		Avail to order Our Price: $48.23

Common repairs and upgrades

PN	Item
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 2 Our Price: $22.44
007021195	Shock Absorber Countach Door Shock Absorber Without Internal Parts you may also need N02214812 x1 HEX.HEAD 007021193 x1 SHOCK ABSOR.FIX.PIN TO DO 007021208 x1 SHOCK ABSORBER SECURPIN A 008580801 x1 O-RING E 8 UNI 7535-75 N01118410 x1 HEX.HEAD CLAMPING NUT WHT002962 x3 WASHER	Current Stock: 6 Our Price: $126.59
007029006	Trunk Lifter Strut Trunk Lifter With Stab.	Current Stock: 4 Our Price: $89.16
007029005	Bonnet Lifter Bonnet Lifter	Current Stock: 2 Our Price: $114.96

Drivetrain

PN	Item
001505914	Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa Oil Cartridge. Note: these are ordered directly from the factory. Brand/Model/Color may differ from the picture. We have no control as to what is sent when they are ordered.	Current Stock: 1 Our Price: $86.51
002136948	Slave Clutch Cylinder Diablo // Countach Slave Clutch Cylinder	Current Stock: 1 Our Price: $134.37
002121294	NLA (No Longer Available) Clutch Mechanism	Avail to order Our Price: $7,000.51
002121675	COUNTACH THOWOUT BEARING Thrust Sleeve	Current Stock: 1 Our Price: $8,632.35

Fuel-Air

PN	Item
07M133843	Air Filter - LM002, Countach, Diablo, Murcielago Please Check your Part Manual for a Description For performance filters see PN: 07M133843A	Avail to order Our Price: $31.69
002021140	Warm Up Regulator Heat Regulator 0438140004 (043 8140 004)	Avail to order Our Price: $1,729.45
002021172	Frequency Valve Frequency Valve Bosch 0280150300 (028 0150 300)	Avail to order Our Price: $872.47
002021173	Fuel Dampers Dampers	Avail to order Our Price: $518.84
002021146	Cold Start Injector Starter Injector	Current Stock: 4 Our Price: $350.78
002021170	Countach Fuel Distributor Fuel Distributor 0438100106 (043 8100 106)	Avail to order Our Price: $5,811.47
002021174	Countach Injection EFI ECU ECU	Avail to order Our Price: $4,741.09
002021141	Countach EFI Fuel Injection Pump SEE ALSO PN 002021141B Fuel Pump	Avail to order Our Price: $1,602.73
002021147	Countach Fuel Injector Injector	Current Stock: 11 Our Price: $318.32
002021176	Lambda O2 Sensor Lambda Sensor The Exact OEM replacement for this is PN 002021176OE you can save by simply using your existing connector.	Avail to order Our Price: $863.24
002021141B	Countach EFI Fuel Injection Pump OEM This is the original and SAME fuel pump used on all Countach EFI systems. It has a different part number, in order to que the order from another vendor rather than the Factory. We would be more than happy to get it from Italy, but it will be the same pump and much more expensive.	Avail to order Our Price: $121.38
001628130	NLA (No Longer Available) Relay/Printed Board Box Unit. This unit is not longer available from the factory.	Avail to order Our Price: $1,232.16
002021145	Accumulator Accumulators	Current Stock: 1 Our Price: $642.09
002021142B	Fuel Filter - Countach - For Fuel Injected EFI This is the original and SAME fuel filter used on all Countach EFI systems. It has a different part number, in order to que the order from another vendor rather than the Factory. We would be more than happy to get it from Italy, but it will be the same pump and much more expensive. As of 1-3-2024 doesn't show availability	Current Stock: 2 Our Price: $38.79
002021173b	Fuel Dampers - For Fuel Injected EFI This is the original and SAME fuel regulator used on all Countach EFI systems. It has a different part number, in order to que the order from another vendor rather than the Factory. We would be more than happy to get it from Italy, but it will be the same pump and much more expensive.	Avail to order Our Price: $339.85
002021176OE	Lambda Sensors Original Equipment Lambda Sensors	Current Stock: 2 Our Price: $126.18
980200016	ADDITIVO X CARB.G 001 700 03 ADDITIVO X CARB.G 001 700 03	Current Stock: 1 Our Price: $16.00
07M133843A	Air Filter - SPORT PERFORMANCE FILTER Performance filter replacement for 07M133843 Air Filter - Murcielago SV LP 670-4	Avail to order Our Price: $782.61

Fuses-Bulbs-Relays

PN	Item
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 4 Our Price: $13.55
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.17
006311154	Relay Relay	Avail to order Our Price: $56.14
006617093	12v 5w Bulb 12v 5w Bulb	Avail to order Our Price: $20.24
006309758	Cylinder Bulb 6411/12v 10w Cylinder Bulb 6411/12v 10w	Avail to order Our Price: $11.85

Gaskets

PN	Item
001526489	Engine Gasket Set - Countach Quatro 5000 Carbureted Engine Gasket Kit - Countach Quatro 5000 Carbureted see pn 001526469 for seals	Avail to order Our Price: $2,229.46
001526469	Grommet and Oil Seals Set - Countach Quatro 5000 Carbureted Grommet and Oil Seals Set Countach Quatro 5000 Carbureted	Avail to order Our Price: $156.06
001526491	NLA (No Longer Available) Engine Gasket Kit see PN 001526471 for seals kit	Avail to order Our Price: $1,431.32
001526471	Countach Quatro Valve USA - Grommet & Oil Seals Set Grommet & Oil Seals Set	Avail to order Our Price: $1,333.23

Ignition

PN	Item	Diagram
001630009	Spark Plug - 12mm Spark Plug		Avail to order Our Price: $39.29
001611403	Countach Wiring Harness Countach Wiring Harness		Avail to order Our Price: $2,876.01

Misc

PN	Item
006111300	Long Wiper Blade Long Wiper Blade	Current Stock: 1 Our Price: $54.20
006128790	Wiper Short Blade 13 inch Wiper Short Blade (Previous PN 006111019)	Current Stock: 2 Our Price: $20.13
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22

Sensors

PN	Item
002021143	Thermostat Switch - EFI Countach only Original OEM Thermostat Switch - INTERR.TERM.0.280.130.214	Current Stock: 3 Our Price: $872.47
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $150.12
001724565	Fan Motor Thermal Contact Fan Motor Thermal Contact	Avail to order Our Price: $244.50
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $169.72
006019052	OIL TEMPERATURE GAUGE OIL TEMPERATURE GAUGE	Avail to order Our Price: $647.05

Open All

Select Group and TAV

< Previous Next >

TAV: 9 - Radiator and Water Circuit

1985 Lamborghini Countach 5000 Quatro USA Radiator and Water Circuit (9)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Countach Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	001710067	Rh Radiator/Supplementary Rese	1 req	Avail to order Our Price: $147.59
2	001711395	Rh Radiator Pipe/Chassis Pipe	1 req	Avail to order Our Price: $35.72
3	008830204	Clamp	2 req	Avail to order Our Price: $10.06
4	001721919	NLA (No Longer Available)	1 req	*See Description
5	008200402	M4 Brass Special Nut	3 req	Current Stock: 2 Our Price: $2.91
6	008410402	Washer D.4.3 Uni 1751 /Zd	3 req	Current Stock: 17 Our Price: $2.00
7	001701645	SEE PN: 1724565 AND 1724564	1 req	Avail to order Our Price: $49.79
8	001705504	Engine Thermal Contact Seal	1 req	Avail to order Our Price: $30.42
9	008100831	Screw M8x30 Uni 5737/8g/Z	8 req	Avail to order Our Price: $2.00
10	WHT001942	WASHER	8 req	Current Stock: 13 Our Price: $3.51
11	WHT001189	RUBBER WASHER MOUNT	8 req	Current Stock: 8 Our Price: $6.78
12	001701592	Radiator Shim	8 req	Current Stock: 8 Our Price: $20.74
13	001701495	Supplementary Reservoir Bracket	8 req	Current Stock: 9 Our Price: $58.42
14	WHT001942	WASHER	8 req	Current Stock: 13 Our Price: $3.51
15	001710068	Lh Radiator/Supplementary Rese	2 req	Avail to order Our Price: $17.38
16	001720302	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
17	008835004	Clamp	14 req	Avail to order Our Price: $10.86
18	001711337	RADIATOR PIPE	3 req	Avail to order Our Price: $627.67
19	001722219	Pipe From Three-Way To Rh Radi	1 req	Avail to order Our Price: $37.31
20	WHT003040	WASHER	8 req	Current Stock: 2 Our Price: $8.12
21	N0211963	HEX.HEAD CLAMPING	8 req	Avail to order Our Price: $2.00
22	001704296	Coolant Cap	1 req	Avail to order Our Price: $155.33
23	001710971	NLA (No Longer Available)	1 req	*See Description
24	008830204	Clamp	4 req	Avail to order Our Price: $10.06
25	001711338	Pipe Protection Sleeve	4 req	Avail to order Our Price: $59.09
26	001722221	Coolant Outlet From Rh Radiato	1 req	Avail to order Our Price: $27.44
27	008830206	Clamp	2 req	Current Stock: 1 Our Price: $23.26
28	001710069	Supplementary Reservoir Drain	1 req	Current Stock: 1 Our Price: $76.25
29	001722223	Three-Way Pipe & Reservoir Out	1 req	Avail to order Our Price: $71.87
30	001722222	Radiator Coolant Return Pump T	1 req	Avail to order Our Price: $689.65
31	001722224	Three-Way ConnectionSleeve To	1 req	Current Stock: 1 Our Price: $52.19
32	008100615	Screw M6x50 Uni 5737/8g	2 req	Avail to order Our Price: $6.79
33	008833801	Front Radiator Coolant Pipe Cl	2 req	Avail to order Our Price: $34.52
34	001722218	Coolant Outlet Three0	1 req	Avail to order Our Price: $622.77
35	001705796	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
36	001728845	Lh Radiator	1 req	Avail to order Our Price: $4,154.24
37	001722220	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
38	001722950	Coolant Pipe To Chassis Clamp	2 req	Current Stock: 1 Our Price: $364.89
39	001720766	Fan Motor Mount Assembly	1 req	Avail to order Our Price: $509.90
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
