1984 Countach 5000s - USA

Group :

Tav :

Maintenance Parts:

Belts

PN	Item	Diagram
001613915	ALTERNATOR DRIVE BELT ALTERNATOR DRIVE BELT - NLA FROM LAMBORGHINI WAREHOUSE - SECONDARY SOURCE		Current Stock: 8 Our Price: $312.98

Brakes

PN	Item	Diagram
003113912	BRAKE PAD BRAKE PAD SET NLA FROM LAMBORGHINI WAREHOUSE - SECONDARY SOURCE		Avail to order Our Price: $44.75

Common repairs and upgrades

PN	Item
007021195	SHOCK ABSORBER COUNTACH DOOR SHOCK ABSORBER WITHOUT INTERNAL PARTS YOU MAY ALSO NEED N02214812 X1 HEX.HEAD 007021193 X1 SHOCK ABSOR.FIX.PIN TO DO 007021208 X1 SHOCK ABSORBER SECURPIN A 008580801 X1 O-RING E 8 UNI 7535-75 N01118410 X1 HEX.HEAD CLAMPING NUT WHT002962 X3 WASHER	Current Stock: 3 Our Price: $117.56
007029005	BONNET LIFTER BONNET LIFTER	Current Stock: 4 Our Price: $106.72
007029006	TRUNK LIFTER STRUT TRUNK LIFTER WITH STAB.	Current Stock: 2 Our Price: $82.81
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 6 Our Price: $27.99

Drivetrain

PN	Item
002109862	CLUTCH PLATE CLUTCH PLATE	Current Stock: 2 Our Price: $1,290.15
002109861	NLA (NO LONGER AVAILABLE) ENGINE FLYWHEEL	Avail to order Our Price: $2,815.50
002109864	THRUST BEARING THRUST BEARING	Avail to order Our Price: $6,806.83
001501188	OIL FILTER - MIURA COUNTACH ESPADA JARAMA OIL FILTER CARTRIDGE	Current Stock: 4 Our Price: $53.39

Fuel-Air

PN	Item
001320172	AIR FILTER - CARBURETED AIR FILTER EARLY COUNTACH, MIURA, JARAMA, ESPADA SEE PN 001320172KN FOR PERFORMANCE FILTER OPTION	Avail to order Our Price: $557.60
002021140	WARM UP REGULATOR / HEAT REGULATOR WARM UP REGULATOR / HEAT REGULATOR	Avail to order Our Price: $1,558.95
002021172	FREQUENCY VALVE FREQUENCY VALVE BOSCH 0280150300 (028 0150 300)	Avail to order Our Price: $940.50
002021173	FUEL DAMPERS FUEL DAMPERS	Avail to order Our Price: $481.14
002021146	COLD START INJECTOR STARTER INJECTOR	Current Stock: 4 Our Price: $389.40
002021170	COUNTACH FUEL DISTRIBUTOR FUEL DISTRIBUTOR 0438100106 (043 8100 106)	Avail to order Our Price: $6,264.87
002021174	COUNTACH INJECTION EFI ECU ECU	Avail to order Our Price: $4,273.56
002021141RE	COUNTACH EFI FUEL INJECTION PUMP FUEL PUMP	Avail to order Our Price: $799.00
002021147	FUEL INJECTOR FOR COUNTACH FUEL INJECTOR FOR COUNTACH	Current Stock: 11 Our Price: $295.65
002021176	LAMBDA O2 SENSOR LAMBDA SENSOR *MAY NEED TO USE YOUR EXISTING CONNECTOR	Current Stock: 4 Our Price: $800.95
002021141	COUNTACH EFI FUEL INJECTION PUMP COUNTACH FUEL INJECTION INLINE FUEL PUMP	Avail to order Our Price: $1,444.72
002021145	ACCUMULATOR ACCUMULATORS	Current Stock: 1 Our Price: $712.98
002021142B	FUEL FILTER - COUNTACH - FOR FUEL INJECTED EFI THIS IS THE ORIGINAL AND SAME FUEL FILTER USED ON ALL COUNTACH EFI SYSTEMS. IT HAS A DIFFERENT PART NUMBER, IN ORDER TO QUE THE ORDER FROM ANOTHER VENDOR RATHER THAN THE FACTORY. WE WOULD BE MORE THAN HAPPY TO GET IT FROM ITALY, BUT IT WILL BE THE SAME PUMP AND MUCH MORE EXPENSIVE. AS OF 1-3-2024 DOESN'T SHOW AVAILABILITY	Avail to order Our Price: $30.48
002021173b	FUEL DAMPERS - FOR FUEL INJECTED EFI THIS IS THE ORIGINAL AND SAME FUEL REGULATOR USED ON ALL COUNTACH EFI SYSTEMS. IT HAS A DIFFERENT PART NUMBER, IN ORDER TO QUE THE ORDER FROM ANOTHER VENDOR RATHER THAN THE FACTORY. WE WOULD BE MORE THAN HAPPY TO GET IT FROM ITALY, BUT IT WILL BE THE SAME PUMP AND MUCH MORE EXPENSIVE.	Current Stock: 1 Our Price: $267.03
002021176OE	LAMBDA SENSORS LAMDA SENSORS	Current Stock: 2 Our Price: $99.14
07M133843KN	K&N AIR FILTER - LM002, COUNTACH, DIABLO, MURCIELAGO K&N'S REPLACEMENT AIR FILTERS ARE DESIGNED TO INCREASE HORSEPOWER AND ACCELERATION WHILE PROVIDING EXCELLENT FILTRATION. THESE FILTERS ARE WASHABLE AND REUSABLE AND ARE CUSTOM DESIGNED TO FIT INTO YOUR EXISTING FACTORY AIR BOX. THEIR DROP-IN DESIGN MEANS ADDING PERFORMANCE IS SIMPLE.	Avail to order Our Price: $55.37
980200016	ADDITIVO X CARB.G 001 700 03 ADDITIVO X CARB.G 001 700 03	Current Stock: 1 Our Price: $14.89
07M133843A	AIR FILTER - SPORT PERFORMANCE FILTER PERFORMANCE FILTER REPLACEMENT FOR 07M133843 AIR FILTER - MURCIELAGO SV LP 670-4	Avail to order Our Price: $728.38
001320172KN	PERFORMANCE FILTER FOR COUNTACH/ESPADA/JARAMA/MIURA HIGH FLOW PERFORMANCE FILTER.	Current Stock: 1 Our Price: $102.16
001501128	OIL FILTER SEAL OIL FILTER SEAL	Current Stock: 2 Our Price: $24.39

Fuses-Bulbs-Relays

PN	Item
006617091	BULB 21W TAIL LIGHT 21W BULB	Current Stock: 4 Our Price: $12.61
006617094	LAMP BA 15S 21W BULB LAMP BA 15S 21W USED IN VARIOUS LAMPS (DEPENDING ON YOUR YEAR AND MODEL)	Current Stock: 76 Our Price: $9.19
N0177522	BULB HEADLIGHT LAMP 12V/3W	Current Stock: 10 Our Price: $2.12
006311154	RELAY RELAY	Avail to order Our Price: $52.06
006617093	12V 5W BULB 12V 5W BULB	Avail to order Our Price: $18.87
006309758	CYLINDER BULB 6411/12V 10W CYLINDER BULB 6411/12V 10W	Avail to order Our Price: $11.06
006617103	3W BULB 3W BULB	Avail to order Our Price: $6.67

Gaskets

PN	Item
001526489	ENGINE GASKET SET - COUNTACH QUATRO 5000 CARBURETED ENGINE GASKET KIT - COUNTACH QUATRO 5000 CARBURETED SEE PN 001526469 FOR SEALS	Avail to order Our Price: $2,403.38
001526469	GROMMET AND OIL SEALS SET - COUNTACH QUATRO 5000 CARBURETED GROMMET AND OIL SEALS SET COUNTACH QUATRO 5000 CARBURETED	Avail to order Our Price: $173.84
001526488	COUNTACH 5000 ENGINE GASKET KIT ENGINE GASKET KIT SEE PN 001526468 FOR SEALS KIT	Avail to order Our Price: $1,464.51
001526468	COUNTACH 5000S GROMMET & OIL SEALS SET - EURO GROMMET & OIL SEALS SET	Avail to order Our Price: $165.04
001526490	COUNTACH 5000 USA - ENGINE GASKET KIT ENGINE GASKET KIT SEE PN 001526470 FOR SEALS KIT	Avail to order Our Price: $1,278.62
001526470	COUNTACH 5000 USA - GROMMET & OIL SEALS SET GROMMET & OIL SEALS SET	Avail to order Our Price: $104.54

Ignition

PN	Item	Diagram
008811403	SPARK PLUG - COUNTACH-JALPA SPARK PLUG		Current Stock: 16 Our Price: $39.99
001611403	COUNTACH WIRING HARNESS COUNTACH WIRING HARNESS		Avail to order Our Price: $3,100.38

Misc

PN	Item
006111300	LONG WIPER BLADE LONG WIPER BLADE	Avail to order Our Price: $50.36
006128790	WIPER SHORT BLADE 13 INCH WIPER SHORT BLADE (PREVIOUS PN 006111019)	Current Stock: 1 Our Price: $18.71
008200605R	OE SPEC ALTERNATIVE FOR 008200605 M6 NCM 70 URAMA SIMMON NUT	Avail to order Our Price: $1.53
400093050D	CTEK US-CD BATTERY CHARGER INPUT 110-120VAC OUTPUT MAX 4.3A, 12V BACK DRAIN LESS THAN 1.5AM/MONTH	Avail to order Our Price: $417.39
0R0000149	CLEANER FLUID 250ML CLEANER FLUID	Current Stock: 1 Our Price: $82.84

Sensors

PN	Item
002409895	REVERSE SWITCH REVERSE SWITCH NLA FROM FACTORY PLEASR CONTACT US FOR CURRENT PRICE AND AVAILABILITY	Avail to order Our Price: $142.08
001801333	OIL & COOLANT TEMPERATURE THERMOMETER OIL & COOLANT TEMPERATURE THERMOMETER NLA FROM FACTORY. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $167.43
002021143	THERMOSTAT SWITCH - EFI COUNTACH ONLY ORIGINAL OEM THERMOSTAT SWITCH - INTERR.TERM.0.280.130.214	Current Stock: 3 Our Price: $940.50
001724565	FAN MOTOR THERMAL CONTACT FAN MOTOR THERMAL CONTACT	Avail to order Our Price: $271.62
001719309	COOLANT THERMOSTAT COOLANT THERMOSTAT FITS THE FOLLOWING: COUNTACH 5000 S, LP400 ESPADA JALPA 3.5 URRACO P30	Avail to order Our Price: $395.00
006019052	OIL TEMPERATURE GAUGE OIL TEMPERATURE GAUGE	Avail to order Our Price: $600.73
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $188.54

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 89 Our Price: $15.26

Open All

Select Group and TAV

< Previous Next >

TAV: 2 - Distribution

1984 Lamborghini Countach 5000s USA Distribution (2)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Countach Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	001219420	DOUBLE ROLLER CHAIN	2 req	Avail to order Our Price: $399.73
2	008101608	SCREW M16X35 UNI 5740/8G	3 req	Avail to order Our Price: $20.09
3	001219432	OIL BREATHER ROTOR	1 req	Avail to order Our Price: $70.44
4	008411701	SNAP RING	3 req	Current Stock: 2 Our Price: $2.76
5	008101608	SCREW M16X35 UNI 5740/8G	2 req	Avail to order Our Price: $20.09
6	001200348	DOWEL CHECK WASHER	2 req	Avail to order Our Price: $17.57
7	001201964	DOWEL	3 req	Avail to order Our Price: $89.74
8	001202917	VALVE BOWL	24 req	Avail to order Our Price: $319.16
9	001201072	VALVE CLEARANCE SHIM	24 req	Avail to order Our Price: $42.38
10	001200233	VALVE RETAINER COTTERS	48 req	Avail to order Our Price: $31.80
11	001200228	VALVE PLATE	24 req	Avail to order Our Price: $473.09
12	001213128	VALVE INNER SPRING	24 req	Avail to order Our Price: $95.66
13	001213129	INNER VALVE SPRING	24 req	Avail to order Our Price: $36.64
14	001202903	VALVE SPRING WASHER	24 req	Avail to order Our Price: $46.94
15	001219430	RUBBER VALVE STEM	24 req	Current Stock: 40 Our Price: $2.92
16	001219717	INTAKE/EXHAUST VALVEGUIDE	24 req	Avail to order Our Price: $61.98
16	001219427	VALVE GUIDE - QV CARB	24 req	Avail to order Our Price: $160.60
17	001210285	INTAKE VALVE SEAT	12 req	Current Stock: 12 Our Price: $34.35
18	001213680	INTAKE VALVE	12 req	Avail to order Our Price: $259.57
19	001201774	EXHAUST VALVE	12 req	Avail to order Our Price: $346.06
20	001210286	EXHAUST VALVE SEAT	12 req	Current Stock: 12 Our Price: $33.39
21	001202694	CAMSHAFT PINION	4 req	Avail to order Our Price: $1,515.70
22	001201965	CAM GEAR DOWEL	1 req	Avail to order Our Price: $99.22
23	001605339	DISTRIBUTOR P.T.O.	1 req	Avail to order Our Price: $201.60
24	WHT000768	SPRING WASHER	1 req	Current Stock: 16 Our Price: $2.12
25	008601502	RING 16 MM OR	2 req	Current Stock: 1 Our Price: $2.76
26	N10738501	ELASTIC PIN 3X32 DIN1481	1 req	Current Stock: 9 Our Price: $0.40
27	008701601	SCREW 16X1.5X23	2 req	Avail to order Our Price: $202.25
28	008401813	WASHER	4 req	Avail to order Our Price: $19.93
29	008803001	BUSHING 30X34X23 MM	2 req	Avail to order Our Price: $72.16
30	001219423	TIGHTENER GEAR	2 req	Avail to order Our Price: $165.32
31	001219425	TIGHTENER PIN	1 req	Avail to order Our Price: $270.76
32	001200336	COVER	1 req	Avail to order Our Price: $392.46
33	008601702	RING 18 MM OR	2 req	Current Stock: 7 Our Price: $3.42
34	001219426	TIGHTENER ADJUSTMENTBRACKET	2 req	Avail to order Our Price: $708.21
35	008300613	STUD	6 req	Avail to order Our Price: $5.37
36	008601702	RING 18 MM OR	2 req	Current Stock: 7 Our Price: $3.42
37	008200605	SIMMON NUT FOR URAMA	4 req	Current Stock: 40 Our Price: $3.35
38	001202447	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
39	001200343	DISTRIBUTION ADJUSTMENT DOWEL	2 req	Avail to order Our Price: $28.88
40	001200345	TIGHTENER DOWEL CHECK WASHER	2 req	Avail to order Our Price: $81.99
41	008411303	SNAP RING 21X13X2.5 UNI 175 1	2 req	Current Stock: 6 Our Price: $3.09
42	008201213	12 UNI 210 8G NUT	2 req	Avail to order Our Price: $5.85
43	008502006	BEARING	2 req	Avail to order Our Price: $47.35
44	001209449	SPACER	2 req	Avail to order Our Price: $101.60
45	001219211	REDUCING GEAR	2 req	Avail to order Our Price: $728.38
46	008502006	BEARING	2 req	Avail to order Our Price: $47.35
47	001209448	BUSHING	2 req	Avail to order Our Price: $143.11
48	008575201	O-RING	2 req	Current Stock: 22 Our Price: $1.40
49	008601801	RING 19 MM OR	2 req	Avail to order Our Price: $13.77
50	001209447	REDUCER GEAR SHAFT	2 req	Avail to order Our Price: $752.55
51	008700613	SCREW M6X14 UNI 5933/8G/ZB	4 req	Avail to order Our Price: $0.20
52	001219428	GUIDE GEAR SHAFT	1 req	Avail to order Our Price: $497.25
53	008522202	NLA (NO LONGER AVAILABLE)	1 req	*See Description
54	001219421	GUIDE GEAR	1 req	Avail to order Our Price: $655.81
55	008604201	RING 43 MM OR	1 req	Current Stock: 9 Our Price: $1.50
56	001213169	LH EXHAUST CAMSHAFT	1 req	Avail to order Our Price: $6,569.31
56	001220548	SWITZERLAND CAMSHAFT	1 req	Avail to order Our Price: $2,983.41
57	001220550	SWITZERLAND CAMSHAFT	1 req	Avail to order Our Price: $2,983.41
57	001213172	LH INTAKE CAMSHAFT	1 req	Avail to order Our Price: $6,569.31
58	001213171	RH INTAKE CAMSHAFT	1 req	Avail to order Our Price: $6,569.31
58	001220551	SWITZERLAND CAMSHAFT	1 req	Avail to order Our Price: $2,983.41
59	001220549	SWITZERLAND CAMSHAFT	1 req	Avail to order Our Price: $2,983.41
59	001213170	RH EXHAUST CAMSHAFT	1 req	Avail to order Our Price: $6,569.31
60	001219422	GUIDE GEAR & DRIVE SHAFT	1 req	Avail to order Our Price: $223.73
61	001219424	DRIVE SPINDLE GUIDE GEAR	1 req	Avail to order Our Price: $684.04
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
