2021 AVENTADOR SVJ COUPE - AUSTRALIA

Maintenance Parts:

Common repairs and upgrades

PN	Item
900000170	Tutela CS Speed Fluid -Oil Lifting System 1 liter Tutela CS Speed Fluid -Oil Lifting System 1 liter	Avail to order Our Price: $67.85
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 2 Our Price: $22.44
4T0803615	Towing Eye TOWING EYE previous part number 400803615	Current Stock: 1 Our Price: $47.87

Ignition

PN	Item	Diagram
470905619C	Spark Plug Spark Plug		Avail to order Our Price: $106.98

Sensors

PN	Item
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $169.72
4H0959126A	AC PRESSURE SENSOR A/C PRESSURE SENSOR,	Avail to order Our Price: $80.25
06A906262AT	OXYGEN SENSOR O2 SENSOR - LAMBDA PROBE OXYGEN SENSOR O2 SENSOR - LAMBDA PROBE	Avail to order Our Price: $154.84

Tools and Tookits

PN	Item	Diagram
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month		Avail to order Our Price: $317.22
69795000805	V12 VALVE SEALING FITTING TOOL V12 VALVE SEALING FITTING TOOL		Avail to order Our Price: $356.21

Open All

Select Group and TAV

< Previous Next >

TAV: 010.01.00 - TYPE PLATES

2021 Lamborghini AVENTADOR SVJ COUPE AUSTRALIA TYPE PLATES (010.01.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Aventador Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
0		GREAT BRITAIN)	0 req
0	4T0010553	STICKER STICKER (WRITTEN IN: CZECH, FRENCH, KOREAN, POLISH,	1 req	Avail to order Our Price: $39.36
0		PORTUGUESE, ROMANIAN, RUSSIAN, SPANISH, TRADITIONAL	0 req
0		CHINESE, TURKISH)	0 req
0	4T0010553B	STICKER STICKER (ENGLISH (ROW))	1 req	Avail to order Our Price: $39.36
0		INDONESIA)	0 req
0		CHILD SAFETY SEAT ON THE FRONT PASSENGERS SEAT, UNLESS	0 req
0		THE PASSENGER AIRBAG IS DEACTIVATED. SIT AS FAR BACK FROM	0 req
0		THE AIRBAG AS POSSIBLE. IF VEHICLE IS EQUIPPED WITH SIDE	0 req
0		AIRBAGS, DO NOT USE SEAT COVERS. ALWAYS WEAR THE SEAT	0 req
0		BELT. AIRBAGS MUST BE REPLACE AFTER 14 YEARS. PLEASE REFER	0 req
0		TO THE OWNERS MANUAL FOR OTHER IMPORTANT NOTES. (ONLY	0 req
0		FOR USA AND CANADA)	0 req
0		PERSONNEL ONLY. VOLKSWAGEN AG	0 req
1	400000297C	PLATE,CHASSIS DATA TAG (SEE IDENTITY PLATE PROCEDURE)	1 req	Avail to order Our Price: $51.44
2	470010522	BRAKE FLUID RESERV NOTICE (VALID FOR: SCANDINAVIA, MEXICO, BRAZIL, TAIWAN, SOUTH KOREA, AUSTRALIA, SINGAPORE, SOUTH AFRICA, ASIA,	1 req	Avail to order Our Price: $8.58
3	470010001A	STICKER INDICAZ INCLINAZ STICKER FOR HEADLIGHT RANGE CONTROL	1 req	Avail to order Our Price: $6.12
4		NOTICE (VALID FOR USA/CANADA MARKETS)	1 req
5	470010778M	STICKER NOTICE	1 req	Avail to order Our Price: $5.59
6	476010525M	IDENTIFICATION EUROPA MAKERS PLATE (SEE IDENTITY PLATE PROCEDURE - VALID FOR: SCANDINAVIA, AUSTRALIA, MEXICO, BRAZIL, RUSSIA, TURKEY,	1 req	Avail to order Our Price: $65.61
6		MAKERS PLATE (SEE REF. 43)	1 req
7		NOTICE QUICKSILVER (VALID FOR USA MARKET)	1 req
8	470010546AS	TIRE LABEL FOR TYRE INFLATION PRESSURE (FOR AUSTRALIA AND NEW ZELAND - STD TIRES)	1 req	Avail to order Our Price: $96.62
8	470010546AT	TIRE LABEL FOR TYRE INFLATION PRESSURE (FOR AUSTRALIA AND NEW ZELAND - SPORT TIRES)	1 req	Avail to order Our Price: $28.48
8		LABEL FOR TYRE INFLATION PRESSURE (ONLY FOR AUSTRALIA AND NEW ZELAND)	0 req
9		NOTICE (VALID FOR USA MARKET)	1 req
10		MAKERS PLATE (VALID FOR USA MARKET)	1 req
11		STICKER FOR FUEL FILLER NECK (SEE REFERENCE : 34)	0 req
12		NOTICE ENGINE DATA (VALID FOR USA/CANADA MARKET)	1 req
13		NOTICE (VALID FOR CANADA MARKET)	1 req
14	400010377T	LABEL STICKER FOR FUEL FILLER NECK	1 req	Avail to order Our Price: $3.13
14	470010001E	STICKER STICKER FOR FUEL FILLER NECK	1 req	Avail to order Our Price: $10.00
15		DATA TAG (VALID FOR USA/CANADA MARKET)	1 req
16		DATA PLATE FOR EMISSION VALUES (VALID FOR USA/CANADA MARKET)	1 req
17	470010521	IDENTIFICATION PLA NOTICE	1 req	Current Stock: 1 Our Price: $11.34
18		INSCRIPTION (SEE ILLUSTRATION 010.04)	0 req
19	8D0000294	FRAME FRAME	1 req	Current Stock: 6 Our Price: $11.99
20	8D0000289	BASIC BRACE HOLDER FOR VEHICLE CHASSIS NUMBER PLATE (SUPPLY VIN)	1 req	Current Stock: 1 Our Price: $4.54
21		LAMBORGHINI EMBLEM (SEE ILLUSTRATION :- 807-020)	0 req
22		LAMBORGHINI EMBLEM (SEE ILLUSTRATION :-REAR 807-040)	0 req
23		STICKER FOR FUSE LAY-OUT (VALID ONLY FOR LEFT- HAND-DRIVE MARKETS- LHD)	1 req
24	472010519E	RELAY BOX STICKER FOR FUSE LAY-OUT ( RHD)	1 req	Avail to order Our Price: $18.79
25	470010518A	RELAY BOX E-BOX STICKER FOR FUSE LAY-OUT	1 req	Avail to order Our Price: $13.70
26		STICKER FOR FUSE LAY-OUT (VALID ONLY FOR LEFT- HAND-DRIVE MARKETS- LHD)	1 req
27	472010503F	FUSE HOLDER STICKER FOR FUSE LAY-OUT ( RHD)	1 req	Avail to order Our Price: $20.99
28		STICKER WITH PICTOGRAM FOR - AIRBAG / CHILDS SEAT (NO PART - VALID FOR ANOTHER MARKET)	0 req
29		MAKERS PLATE (VALID FOR CHINA MARKET)	1 req
30	470010539A	WARNING STICKER MAKERS PLATE	1 req	Avail to order Our Price: $32.28
31	470000107H	PLATE INSCRIPTION (1 OF 900)	1 req	Avail to order Our Price: $767.83
31	470000107K	PLATE INSCRIPTION (ONLY FOR LIVRERY - 1 OF 63)	1 req	Avail to order Our Price: $2,519.63
31	470000107M	PLATE PERSONALIZED INSCRIPTION (AD-PERSONAM - SUPPLY VIN)	1 req	Avail to order Our Price: $2,519.63
32	WHT005881	FLAT HEAD BOLT COUNTERSUNK BOLT (ST2.5X13)	2 req	Current Stock: 3 Our Price: $3.95
33		DATA TAG (NOT FOR THIS MARKET)	1 req
34	476010508A	STICKER, FUEL AUSTRALIA DATA PLATE (FUEL CONSUPTION)	1 req	Avail to order Our Price: $155.81
35		MAKERS PLATE (NOT FOR THIS MODEL/ MARKET)	1 req
35		MAKERS PLATE (ONLY FOR ROADSTER)	0 req
36		MAKERS PLATE (NOT FOR THIS MARKET - ONLY FOR RUSSIA)	1 req
37		MAKERS PLATE (ONLY FOR SV - ONLY FOR RUSSIA MARKET)	1 req
38		MAKERS PLATE (NOT FOR THIS MODEL/ MARKET)	1 req
39		NOTICE ENGINE DATA (ONLY FOR SV - UNLY FOR USA, CANADA)	1 req
40		NOTICE ENGINE DATA (NO PART - ONLY FOR CHINA MARKET)	0 req
41		STICKER -WARNING- SAFETY PRECAUTIONS THE VEHICLE IS EQUIPPED WITH AIRBAG. DO NOT INSTALLL A REERWARD- FACING	0 req
42		MAKERS PLATE (NO PART - ONLY FOR CHINA MARKET)	0 req
43		NOTICE (NO PART - ONLY FOR CHINA MARKET)	0 req
44	470010515A	AIR CONDITIONING HAFTETIKETTE STICKER AIR CONDITIONING REFRIGERANT R-12,CHARGE LEVEL .... GRMS. CAUTION: SYSTEM TO BE SERVI- CED BY QUALIFIED	1 req	Avail to order Our Price: $81.26
45	470010003	FUEL TYPE KRAFTSTOFFVERBRAUC STICKER BLEIFREI SUPER MIN.ROZ/RON95 PREMIUM UNLEADED FUEL ONLY SUPER CARBURANT SANS PLOMB	1 req	Avail to order Our Price: $7.46
46		DATA PLATE (NOT FOR THIS MARKET)	0 req
47	400010502D	TIRE PRESSURE STICKER (TPMS AT 433 MHZ)	1 req	Avail to order Our Price: $57.56
47	400010502E	TIRE PRESSURE STICKER (TPMS AT 315 MHZ)	1 req	Avail to order Our Price: $494.99
48		WARNING SIGN (NOT FOR THIS MARKET - ONLY FOR USA)	0 req
49		DATA PLATE (STICKER FOR FUEL FILLER NECK - ONLY FOR EUROPE MARKET)	0 req
50		LABEL (ONLY FOR SVJ AND ONLY FOR CHINA MARKET)	0 req
51		STICKER, ENGINE DATA "F.." (ONLY FOR CHINA)	0 req
52		STICKER FOR AIR CONDITIONER	0 req
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
